Product Overview
Hofmann monty® 3850 Heavy-Duty Truck Tire Changer
Built for demanding commercial tire service, the Hofmann monty® 3850 is a professional-grade tire changer for tube-type and tubeless wheel assemblies used on buses, tractor-trailers, commercial trucks, and other heavy-duty vehicles. Its hydraulic operation, self-centering four-jaw chuck, and combined bead-breaking and mount/demount system help one technician handle large wheel assemblies with control and confidence.
The monty 3850 accommodates rims from 14 to 26 inches, wheels up to 59 inches in diameter, and wheel assemblies weighing up to 2,205 pounds. A wired mobile control unit lets the operator manage tire-changing functions from a safer working position while maintaining a clear view of the job.
Built for Heavy-Duty Productivity
- Wide application range: Services tube-type and tubeless tires for commercial trucks, buses, and tractor-trailers.
- One-technician operation: The wired mobile control console keeps operating functions within easy reach.
- Hydraulic clamping: A self-centering four-jaw chuck securely positions the wheel for service.
- Integrated working tool: The combined bead-breaker disk and mount/demount head supports efficient work from both sides of the wheel.
Key Features
Technical Specifications
| Model / Part Number | EEWH703AUA |
|---|---|
| Rim Clamping Range | 14–26 in (36–66 cm) |
| Maximum Wheel Width | 27.5 in (70 cm) |
| Maximum Wheel Diameter | 59 in (150 cm) |
| Maximum Wheel Weight | 2,205 lb (1,000 kg) |
| Power Supply | 208V, 1-phase, 60Hz |
| Dimensions (H × W × D) | 58 × 83 × 83 in (148 × 210 × 210 cm) |
Before Ordering
Confirm the available 208V single-phase electrical service, installation space, access route, and unloading requirements before purchase. Specifications may change; contact us if you need help confirming fit for a particular wheel or application.
